Best Mitsubishi Semi-Hermetic Type Spare Parts

0…VII

This model series has proved successful over decades all over the world. By a continuous development and the use of high-quality materials it sets up – now as ever – the international quality standard.

Specifications:

Displacement min. / max. in m³/h

  • 0 (0.81-1.80)
  • I (1.44-2.02)
  • II (2.26-4.52)
  • III (4.10-9.42)
  • IV (7.56-14.92)
  • V (13.06-28.61)
  • VI (24.50-44.00)
  • VII (42.00-58.00)
2N-T

BITZER is the way forward with the .2-Generation. One common compressor series for chlorine free HFC refrigerants and the HCFC’s. Due to the highly efficient and especially robust design the standard compressors have the design features for operation with chlorinated as well as with chlorine free refrigerants. The only difference in case of chlorine free substitutes is the use of Polyol-Ester oils approved by BITZER and a new shaft seal for 2T.2Y to 4N.2Y.



Specifications:

  • 2N.2 (28.0/33.8)
  • 2T.2 (19.7/23.7)
4J..6F

BITZER is the way forward with the .2-Generation. One common compressor series for chlorine free HFC refrigerants and the HCFC’s. Due to the highly efficient and especially robust design the standard compressors have the design features for operation with chlorinated as well as with chlorine free refrigerants. The only difference in case of chlorine free substitutes is the use of Polyol-Ester oils approved by BITZER.



Specifications:

Displacement min. / max. in m³/h

  • 4H.2 (73.6/88.8)
  • 4G.2 (84.5/102.0)
  • 6H.2 (110.5/133.4)
  • 6G.2 (126.8/153.0)
  • 6F.2 (151.6/183.0)
4N-T

BITZER is the way forward with the .2-Generation. One common compressor series for chlorine free HFC refrigerants and the HCFC’s. Due to the highly efficient and especially robust design the standard compressors have the design features for operation with chlorinated as well as with chlorine free refrigerants. The only difference in case of chlorine free substitutes is the use of Polyol-Ester oils approved by BITZER and a new shaft seal for 2T.2Y to 4N.2Y.



Specifications:

Displacement min. / max. in m³/h
  • 4N.2 (56.1/67.7)
  • 4T.2 (39.4/47.5)
